This is dedicated to the next few months.
The creation of a new rocket from concept to flight.
Highlights, if you will... atleast some of them anyway.
BASICS
- 10" nominal diameter sonotube airframe.
- 10-11 feet tall
- 150lbs expected weight.
- Loki N3800 motor 12,500ns ~ 1,000lbs of thrust for 3 seconds. *(not quite a PBR official ride time)*
- Dual Deployment.
- 4 Fins and A Nose Cone.
THIS WILL BE FUN... or I have already failed at the most important parameter!!!!
A peek of the plan!
CONSTRUCTION BEGINS
 |
| Start with a BIG tube. |
 |
| A tube for the motor. |
 |
| Yep, looks like its going to fit. |
 |
| Measure twice, cut once. |
 |
| Diameter is 1/2 of the important measurements. |
 |
| Circumfrence is the other 1/2 of important measurements. |
 |
| MATH... UGHHH. |
 |
| Charting sugar in the blood stream.(not really rocket but hey.. it,s science) |
 |
| Not quite differential equations. |
 |
| 1 would be boring, we will drill 4 to make it even numbered. |
 |
| Saws are childs play. |
 |
| Proud of the successful cut. |
 |
| FINS, you gotta have'em |
 |
| An easy way to make small format (11x17) to large format (32 x 40) |
 |
| spray glue, good for lotioning hands :) yea right? |
 |
| Cut out! |
 |
| Cut out more fins. |
 |
| Weight test, passes, just barely. |
 |
| Exact length of fin is very important, I tack them together, and do a cut with the miter saw, so that all 4 fins are the exact same length. |
 |
| Tack fins to bevel jig. |
 |
| Beveling fins with table saw (sucky part) |
 |
| Tacking fins on with epoxy. |
 |
| All Cut and trimmed and ready for flight. |
 |
| All fins tacked and ready for structural fillets. |
